Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Configuration | Enclosed |
| Input Voltage | 18-76 VDC |
| Mounting Type | DIN Rail |
| Number of Outputs | 1 |
| Operation | Switching |
| Output | 12VDC@5A |
| Output Power | 60 W |
| Output Voltage | 12 VDC |
| Primary Type | DC-DC |
| Series | |
| Special Features | 3-Years Product Warranty, Output Voltage Adjustable, Overload and Short Circuit Protection, Low Ripple and Noise |
| Type | Industrial |
Overview
In the TCL range of DIN-rail power supplies are 5 models for DC input voltage available. The wide input ranges of 9.5-18 VDC resp. 18-75 VDC means these models can be operated from all popular DC supply voltage systems. With tightly regulated output voltage these DC/DC converters provide a reliable power source for sensitive loads in industrial process controls, factory automation and other equipment exposed to a critical industrial environment. Further applications for these converters are isolation of a specific load or refreshing the 24 V bus voltage. Easy installation is provided with snap-on mounting on DIN-rails and detachable screw terminal block.
Features:
