Hydraulic Breaker

The CID Hydraulic Breakers are the perfect attachment for rock, asphalt, or concrete demolition. Our Hydraulic Breakers are available in eight different models suitable for mini-skid steers, skid steers, compact loaders, and mini-excavators. CID also offers a variety of working tools for your Breaker: Cone points, Cross cut asphalt cutters, Inline Asphalt cutters, Asphalt cutters, Tamping tools, and Post drivers.

Model Specifications

Longer Chisel Point and larger through bolt for added durability
Stronger impact power, low noise design
Control valve replaceable with ease and speed
All Breakers include: Mount, Hoses, Moil Point, Blunt Point, Tool Kit, Nitrogen Gauge, and Operator’s Manual
Two Year Warranty(Wear parts excluded)
Auto Lube standard on four models, CBR1000 and above
Additional Tool Tips available

SPECIFICATIONS

Description	Unit	CBR225	CBR500	CBR650	CBR850	CBR1000
Impact Energy Class	ft lb.	359	500	650	850	1000
Operation Weight	lb.	359	551	716	1069	1179
Hose Length	in.	.5" x 90"	.5 " x 110"	.5" x 110"	.75" x 110"	.75" x 110"
Blow Rate (Long Stroke)	bpm	540~1000	600~1490	550~1300	380~1100	380~1000
Required Oil Flow	gpm	3.97~9.25	5.28~18.49	7.92~18.49	10.03~29.05	11.88~36.98
Operating Pressure	psi	1280~1707	1280~2702	1565~2702	1707~2702	1991~2702
Tool Diameter	in.	1.77"	2.24"	2.75"	2.95"	3.14"
Suitable Carrier	ton	.8~2.5	1.5~4	3~6	4.5~8	4.5~8.8
Suitable Carrier	lb.	1600~5000	3000~8000	6000~12000	9000~16000	9000~17600
